Compare Router models
Compare other series? Check
SD Switches and AP One .
_Front.png)
Quick Look
No differences
Number of Ethernet WAN port
0 / 1 (GE) 1
Available with PrimeCare Subscription, complimentary for the first year. PrimeCare Enables Ethernet WAN, Wi-Fi WAN, Hot Failover, and Smoothing. Alternatively, without a PrimeCare Subscription, Feature pack license (MAX-BR1-MINI-FP) is required to activate the perpetual license for the aforementioned features.
Number of Ethernet WAN port
1 / 0 (2.5G) 2
WAN port(s) can be configured as LAN port(s) via the Web Admin. Ethernet ports include surge and ESD protection circuits to protect against over-voltage transients.
Number of Ethernet WAN port
3 / 2 (GE) 3
WAN 3 is configured as a LAN port by default, configuration is changeable on the Web Admin.
Number of Ethernet LAN port
3 / 2 (GE) 1
Available with PrimeCare Subscription, complimentary for the first year. PrimeCare Enables Ethernet WAN, Wi-Fi WAN, Hot Failover, and Smoothing. Alternatively, without a PrimeCare Subscription, Feature pack license (MAX-BR1-MINI-FP) is required to activate the perpetual license for the aforementioned features.
Number of Ethernet LAN port
2 / 3 (GE) 2
WAN port(s) can be configured as LAN port(s) via the Web Admin. Ethernet ports include surge and ESD protection circuits to protect against over-voltage transients.
Number of Ethernet LAN port
8 / 9 (GE) 3
WAN 3 is configured as a LAN port by default, configuration is changeable on the Web Admin.
Router Throughput
300Mbps
Router Throughput
1Gbps
Router Throughput
2.5Gbps
SpeedFusion VPN Throughput (No Encryption)
80Mbps
SpeedFusion VPN Throughput (No Encryption)
400Mbps
SpeedFusion VPN Throughput (No Encryption)
600Mbps
SpeedFusion VPN Throughput (256-bit AES)
200Mbps
SpeedFusion VPN Throughput (256-bit AES)
500Mbps
Number of Cellular Modem
1
Number of Cellular Modem
1
Number of Cellular Modem
4
Interfaces
No differences
Maximum Ethernet WAN / LAN port configuration
1 WAN with 2 LAN
0 WAN with 3 LAN
Maximum Ethernet WAN / LAN port configuration
1 WAN with 2 LAN
0 WAN with 3 LAN
Maximum Ethernet WAN / LAN port configuration
3 WAN with 8 LAN
2 WAN with 9 LAN
SFP LAN / WAN
No
SFP LAN / WAN
No
SFP LAN / WAN
No
Serial Interface
No
Serial Interface
No
Serial Interface
No
Wi-Fi AP
Yes
Wi-Fi AP
Yes
Wi-Fi AP
Yes
Wi-Fi WAN
Yes 1
Available with PrimeCare Subscription, complimentary for the first year. PrimeCare Enables Ethernet WAN, Wi-Fi WAN, Hot Failover, and Smoothing. Alternatively, without a PrimeCare Subscription, Feature pack license (MAX-BR1-MINI-FP) is required to activate the perpetual license for the aforementioned features.
Wi-Fi WAN
Yes
Wi-Fi WAN
Yes
USB WAN
No
USB WAN
No
USB WAN
Yes (2x USB)
Module Expansion
No
Module Expansion
No
Module Expansion
Yes
Performance
No differences
Number of Recommended Users
1–60
Number of Recommended Users
1–150
Number of Recommended Users
50–500
Wireless details
No differences
Cellular Modem Category options
1x 5G
Cellular Modem Category options
1x 5G
Cellular Modem Category options
4x 5G
5G support
Yes
5G support
Yes
5G support
Yes
SIM Slots
2
SIM Slots
2
SIM Slots
8
SIM Card Size
Nano-SIM (4FF)
SIM Card Size
Nano-SIM (4FF)
SIM Card Size
Mini-SIM (2FF)
Wi-Fi Radio
Dual (2.4GHz + 5GHz) 6
2x2 Wi-Fi 5
Wi-Fi functionality is available with BR1 Mini 5G (HW2).
Wi-Fi Radio
Dual (2.4GHz + 5GHz)
2x2 Wi-Fi 6
Wi-Fi Radio
Dual (2.4GHz + 5GHz)
2x2 Wi-Fi 5
Wi-Fi Antenna Transmit Power (2.4GHz, single chain)
20dBm
Wi-Fi Antenna Transmit Power (2.4GHz, single chain)
24dBm
Wi-Fi Antenna Transmit Power (2.4GHz, single chain)
24dBm
Wi-Fi Antenna Transmit Power (5GHz, single chain)
20dBm
Wi-Fi Antenna Transmit Power (5GHz, single chain)
26dBm
Wi-Fi Antenna Transmit Power (5GHz, single chain)
21dBm
Multiple SSIDs
16
Multiple SSIDs
16
Multiple SSIDs
16
GPS
No
GPS
Yes
GPS
Yes
RemoteSIM (used in SIM Injector)
Yes
RemoteSIM (used in SIM Injector)
Yes (HW2+)
RemoteSIM (used in SIM Injector)
Yes
FusionSIM
Yes
FusionSIM
Yes (HW2+)
FusionSIM
Yes
Peplink eSIM Data Plans
Yes
Features
No differences
SpeedFusion Hot Failover
Yes 1
Available with PrimeCare Subscription, complimentary for the first year. PrimeCare Enables Ethernet WAN, Wi-Fi WAN, Hot Failover, and Smoothing. Alternatively, without a PrimeCare Subscription, Feature pack license (MAX-BR1-MINI-FP) is required to activate the perpetual license for the aforementioned features.
SpeedFusion Hot Failover
Yes
SpeedFusion Hot Failover
Yes
SpeedFusion Smoothing
Yes 1
Available with PrimeCare Subscription, complimentary for the first year. PrimeCare Enables Ethernet WAN, Wi-Fi WAN, Hot Failover, and Smoothing. Alternatively, without a PrimeCare Subscription, Feature pack license (MAX-BR1-MINI-FP) is required to activate the perpetual license for the aforementioned features.
SpeedFusion Smoothing
Yes
SpeedFusion Smoothing
Yes
SpeedFusion Bandwidth Bonding
Yes 1
Available with PrimeCare Subscription, complimentary for the first year. PrimeCare Enables Ethernet WAN, Wi-Fi WAN, Hot Failover, and Smoothing. Alternatively, without a PrimeCare Subscription, Feature pack license (MAX-BR1-MINI-FP) is required to activate the perpetual license for the aforementioned features.
SpeedFusion Bandwidth Bonding
Yes
SpeedFusion Bandwidth Bonding
Yes
SpeedFusion Connect
Yes 9
PrimeCare subscription includes 500 GB/year complimentary SpeedFusion Connect Usage data.
SpeedFusion Connect
Yes 10
PrimeCare subscription includes 1TB/year complimentary SpeedFusion Connect Usage data.
SpeedFusion Connect
Yes 11
CarePlan subscription includes 2TB/year complimentary SpeedFusion Connect Usage data.
SpeedFusion Relay Mode (Server)
Yes
SpeedFusion Relay Mode (Server)
Yes
SpeedFusion Relay Mode (Server)
Yes
Drop-In Mode
Yes
Drop-In Mode
Yes
Drop-In Mode
Yes
High Availability
Yes
High Availability
Yes
High Availability
Yes
Peplink AP Series Management
No
Peplink AP Series Management
Yes
Peplink AP Series Management
Yes
Remote AP & Multiple Config Profiles Management
No
Remote AP & Multiple Config Profiles Management
No
Remote AP & Multiple Config Profiles Management
No
WAN as LAN
Yes
WAN as LAN
Yes
WAN as LAN
Yes
LAN Bypass
No
LAN Bypass
No
LAN Bypass
No
InTouch
Yes
InTouch
Yes
InTouch
Yes
Virtual WAN
Yes 12
1 Virtual WAN complimentary with active PrimeCare. Up to 3 Virtual WAN upon purchasing Virtual WAN Activation Licence.
Virtual WAN
Yes 12
1 Virtual WAN complimentary with active PrimeCare. Up to 3 Virtual WAN upon purchasing Virtual WAN Activation Licence.
Synergy Mode (Controller)
Yes
Synergy Mode (Controller)
Yes
Synergy Mode (Controller)
Yes
Synergized Device
Yes
Synergized Device
Yes
Synergized Device
Yes
Application and Web Blocking
Yes
Application and Web Blocking
Yes
Application and Web Blocking
Yes
Web Content Filtering
Lite
Web Content Filtering
Lite
Web Content Filtering
Lite
IPv6
No
IPv6
No
IPv6
Yes
x.509 Certificate
Yes
Captive Portal
Yes
Captive Portal
Yes
Captive Portal
Yes
GPIO
Yes
GPIO
Yes
GPIO
Yes
Ignition Sensing
Yes
Ignition Sensing
Yes
Ignition Sensing
Yes
Netflow support
Yes
Netflow support
Yes
Netflow support
Yes
LACP (802.3ad) NIC Bonding
No
Internal Storage for Edge Computing
No
Internal Storage for Edge Computing
No
Internal Storage for Edge Computing
Yes 17
Available with MBX MediaFast version. Support Application, Docker, KVM. Please contact Peplink Business Development team for details.
External Storage via USB Port
No
External Storage via USB Port
No
Dead Reckoning
No
Dead Reckoning
Yes
Dead Reckoning
Yes
Core Functionality
No differences
Inter-VLAN Routing
Yes
Inter-VLAN Routing
Yes
Inter-VLAN Routing
Yes
802.1q VLANs Supported
16
802.1q VLANs Supported
16
802.1q VLANs Supported
128
Port-Based VLAN
Yes
Port-Based VLAN
Yes
Port-Based VLAN
Yes
Load Balancing Algorithms
8
Load Balancing Algorithms
8
Load Balancing Algorithms
8
Load Balancing & Failover
Yes
Load Balancing & Failover
Yes
Load Balancing & Failover
Yes
Inbound Load Balancing
No
Inbound Load Balancing
No
Inbound Load Balancing
No
InControl 2 Cloud Management
Yes
InControl 2 Cloud Management
Yes
InControl 2 Cloud Management
Yes
InControl GPS Fleet Management
No
InControl GPS Fleet Management
Yes
InControl GPS Fleet Management
Yes
Advanced QoS Functionality
No differences
Bandwidth Usage Monitoring
Yes
Bandwidth Usage Monitoring
Yes
Bandwidth Usage Monitoring
Yes
QoS for VoIP and E-Commerce
Yes
QoS for VoIP and E-Commerce
Yes
QoS for VoIP and E-Commerce
Yes
User Groups Bandwidth Control
Yes
User Groups Bandwidth Control
Yes
User Groups Bandwidth Control
Yes
VPN Functionality
No differences
SpeedFusion VPN
Yes
SpeedFusion VPN
Yes
SpeedFusion VPN
Yes
Number of SpeedFusion VPN Peers
2 or 5 19
2 SpeedFusion VPN Peers are enabled by default. 5 SpeedFusion VPN Peers are enabled with PrimeCare Subscription, complimentary for the first year.
Number of SpeedFusion VPN Peers
2 or 5 19
2 SpeedFusion VPN Peers are enabled by default. 5 SpeedFusion VPN Peers are enabled with PrimeCare Subscription, complimentary for the first year.
Number of SpeedFusion VPN Peers
3 or 20 or 50 20
With purchase of optional SpeedFusion License (MAX-HD-020-SPF / SFN-LC-50) can connect to up to 20 / 50 SpeedFusion VPN peers respectively.
IPsec VPN
Yes
IPsec VPN
Yes
IPsec VPN
Yes
Number of IPsec Tunnels
5
Number of IPsec Tunnels
5
Number of IPsec Tunnels
5
L2TP VPN / Open VPN / PPTP VPN Server
Yes
L2TP VPN / Open VPN / PPTP VPN Server
Yes
L2TP VPN / Open VPN / PPTP VPN Server
Yes
Maximum PPTP / L2TP / OpenVPN Users
3
Maximum PPTP / L2TP / OpenVPN Users
3
Maximum PPTP / L2TP / OpenVPN Users
15
Remote RADIUS / LDAP authentication in Remote User Access
No
Remote RADIUS / LDAP authentication in Remote User Access
No
Remote RADIUS / LDAP authentication in Remote User Access
Yes
Number of OpenVPN Tunnel (Site to Site)
5
Number of OpenVPN Tunnel (Site to Site)
5
Number of OpenVPN Tunnel (Site to Site)
5
Number of GRE Tunnel (Site to Site)
5
Number of GRE Tunnel (Site to Site)
5
Number of GRE Tunnel (Site to Site)
5
Hardware
No differences
Enclosure
Compact
Indoor Metal
Enclosure
Indoor
Metal
Enclosure
Indoor
Metal
4pin Molex Micro-Fit Connector
Yes
4pin Molex Micro-Fit Connector
Yes
4pin Molex Micro-Fit Connector
No
Terminal Block Power Connector for Mobile / Vehicular Deployment
No
Terminal Block Power Connector for Mobile / Vehicular Deployment
No
Terminal Block Power Connector for Mobile / Vehicular Deployment
Yes
AC Adapter or PSU
AC Input 100V–240V
DC Output 12V 2A
AC Adapter or PSU
AC Input 100V–240V
DC Output 12V 2A
AC Adapter or PSU
AC Input 100V–240V
DC Output 54V 3.34A
Input voltage
DC 10–30V
Input voltage
DC 10–30V
Input voltage
DC 12–56V
PoE Input
Yes
PoE Input
No
PoE Input
No
PoE Output
No
PoE Output
No
PoE Output
Up to 8x 802.3at PoE 21
2x 54V DC input is needed for all 8x LAN ports to have 802.3at PoE. Plugging in 1x 54V DC input will result in 4x LAN ports having 802.3at PoE.
USB Power Input
No
USB Power Input
No
USB Power Input
No
Nominal Power Consumption
13W
Nominal Power Consumption
8W
Nominal Power Consumption
NA
Maximum Power Consumption
18W
Maximum Power Consumption
19W
Maximum Power Consumption
55W (w/o PoE)
Dimensions in inches
4.95 x 4.2 x 1.4 inches
Dimensions in inches
5.78 x 5.08 x 1.15 inches
Dimensions in inches
1.7 x 11.5 x 7.0 inches
Dimensions in mm
125.7 x 107 x 35 mm
Dimensions in mm
146.8 x 129 x 29.3 mm
Dimensions in mm
43 x 292 x 177 mm
Weight (Pound)
0.93 pounds
Weight (Pound)
1.5 pounds
Weight (Pound)
7.28 pounds
Weight (Gram / Kilogram)
425 grams
Weight (Gram / Kilogram)
680 grams
Weight (Gram / Kilogram)
3.3 kg
Operating Temperature
-40°–149°F
-40°–65°C
Operating Temperature
-40°–149°F
-40°–65°C
Operating Temperature
-40°–149°F
-40°–65°C
Humidity
15%–95% (non-condensing)
Humidity
15%–95% (non-condensing)
Humidity
15%–95% (non-condensing)
Rack-mount
No
Rack-mount
No
Rack-mount
No
Dual Hot Swap Power Supply
No
Dual Hot Swap Power Supply
No
Dual Hot Swap Power Supply
No
Warranty Info
No differences
Warranty
1-Year Limited Warranty
Warranty
1-Year Limited Warranty
Warranty
1-Year Limited Warranty
