Certified at:
Built to Last
Sturdy industrial-strength designed for continuous high-traffic operation.
Portable
The light and sleek enclosure offers portability in the palm of your hands.
Stay Connected
With two SIM slots and an eSIM, the MAX Adapter always has a way to connect.
Compatible with 5G
MAX Adapter now offers a 5G compatible device option. Bringing 5G connectivity to your devices.
SpeedFusion Connect
With a built-in eSIM, achieving on-demand data to minimize data wastage and optimize your connectivity is simple. Do not settle for less, choose SpeedFusion Connect.
Connect with
Peplink Products
Protect and reinforce products^ with a USB port
and make it a 5G/LTE WAN.
^For compatible models, please refer to the MAX Adapter FAQ.
Windows & Linux* Devices
Providing 5G or LTE connectivity
for Windows and Linux devices on-the-go.
* For users on the Linux, please refer to our MAX Adapter
user manual to set up.
Non-Peplink Devices
Place anywhere to optimize cellular reception, reduce truck rolls, expand infrastructure, and maximize uptime for businesses that require always-on connectivity.
-
Cellular WAN Interfaces Single LTE Modem Redundant SIM Slot Yes Downlink/Uplink
DatarateCAT-12: 600 Mbps/150 Mbps
CAT-6: 300Mbps/50MbpsAntenna Connectors 2x SMA Cellular, 1x SMA GPS Power Input 5V USB-C Power Consumption 5W (nominal), 8W (max.) SIM Slots 2 SIM Card Size Nano-SIM (4FF) Dimensions 3.9 x 2.8 x 0.6 inches /
100 x 71 x 15 mmWeight 120g Operating Temperature 32° – 104°F / 0° – 40°C Humidity 15% – 95% (non-condensing) Warranty 1-Year Limited Warranty Certifications FCC, IC Package Content MAX Adapter,
2x 2dBi 4G LTE Antennas,
USB-C Female to USB-A Male Adapter,
USB-C power cable -
Cellular WAN Interfaces Single 5G Modem Redundant SIM Slot Yes Downlink/Uplink
Datarate5G: 4 Gbps / 700 Mbps
LTE CAT-20: 2 Gbps / 150 MbpsAntenna Connectors 4x SMA Cellular Power Input 5V USB-C Power Consumption 5W (nominal), 8W (max.) SIM Slots 2 SIM Card Size Nano-SIM (4FF) Dimensions 3.9 x 2.8 x 0.6 inches /
100 x 71 x 15 mmWeight 120g Operating Temperature 32° – 104°F / 0° – 40°C Humidity 15% – 95% (non-condensing) Warranty 1-Year Limited Warranty Certifications FCC, CE, IC Package Content MAX Adapter 5G,
4x 2dBi 4G LTE Antennas,
USB-C Female to USB-A Male Adapter,
USB-C power cable -
The MAX Adapter is compatible with models which have a USB WAN port. To set up and use your MAX Adapter with a compatible device, you must install operating Firmware 8.1.1 or higher.
Full list of devices compatible with the MAX Adapter (LTE):
Full list of devices compatible with the MAX Adapter (5G):
-
Q. What is the MAX Adapter and how do I use it?
The MAX Adapter is a state-of-the-art cellular modem by Peplink, it is not a standalone router. It can be used in two ways to:
- Add an additional cellular WAN to your existing Peplink device which has a USB WAN port. Check here to see how it works.
- Provide 5G or LTE connectivity to your Windows or Linux devices on-the-go, acting as a cellular modem.
Q. Is the MAX Adapter right for me?
Are you in need of a solution that can add an additional 5G/LTE WAN to existing Peplink products via a USB WAN port, supports SpeedFusion VPN, offers external antenna support, has dual SIM slots, and is something small but not a full router? Then the MAX Adapter is for you!
Q. Do antennas come included?
Four LTE antennas are included but the GPS antenna must be purchased separately.
Q. Can I pair my MAX Adapter with my Mac?
Currently, our MAX Adapter is only compatible with Windows & Linux devices.
Q. Does the MAX Adapter have a built-in battery?
No, the MAX Adapter is powered via USB-C.
Q. My MAX Transit has a USB port but it’s not compatible with the MAX Adapter. Why?
The MAX Transit’s USB port only provides power input, not data. For compatibility, the device must contain a USB WAN port.
-
MAX Adapter (LTE)
Product Code Carrier/Category 4G Bands 3G Bands MAX-ADP-LTEA-K-T Global
CAT-12B1, B2, B3, B4, B5, B7, B8, B9, B12, B13,
B18, B19, B20, B26, B28, B29, B30, B32,
B41, B42, B43, B46, B48, B66
HSPA+: B1, B2, B4, B5, B6, B8, B9,
B19MAX-ADP-LTEA-R-T America^
CAT-12B1, B2, B3, B4, B5, B7, B8, B9, B12, B13,
B14, B18, B19, B20, B26, B29, B30, B32,
B41, B42, B43, B46, B48, B66HSPA+: B1, B2, B4, B5, B6, B8, B9, B19 MAX-ADP-LTEA-W-T Global
CAT-6B1, B2, B3, B4, B5, B7, B8 , B12, B13, B20,
B25, B26, B29, B30, B41WCDMA/HSPA+/DC-HSPA+:
B1, B2, B3, B4, B5, B8^ US Carrier Certifications: AT&T, Verizon, FirstNet
MAX Adapter (5G)
Product Code Carrier/Category 5G Bands LTE Bands MAX-ADP-5GH-T Global / 5G* 5G (NSA) Sub 6Ghz:
n1, n2, n3, n5, n28, n41,
n66, n71, n77, n78, n79
B1, B2, B3, B4, B5, B7, B8, B12, B13,
B14, B17, B18, B19, B20, B25, B26,
B28, B29, B30, B32,B34, B38, B39,
B40, B41, B42, B46, B48, B66, B71* US Carrier Certifications: AT&T, T-Mobile, US Cellular, Verizon (C-Band), FirstNet
-
Product Code Description ACW-232 GPS Antenna *Not applied to MAX Adapter 5G SVL-MAX-ADP-LTEA-RK-1Y 1-Year EssentialCare for MAX Adapter LTEA SVL-MAX-ADP-LTEA-RK-2Y 2-Year EssentialCare for MAX Adapter LTEA SVL-MAX-ADP-5G-1Y 1-Year EssentialCare for MAX Adapter 5G SVL-MAX-ADP-5G-2Y 2-Year EssentialCare for MAX Adapter 5G ICS-012 1-Year InControl 2 Subscription ICS-024 2-Year InControl 2 Subscription ECP-A-1Y EssentialCare+ A (1-Year), for LTEA (CAT-6) ECP-A-2Y EssentialCare+ A (2-Year), for LTEA (CAT-6) ECP-A-4Y EssentialCare+ A (4-Year), for LTEA (CAT-6) ECP-B-1Y EssentialCare+ B (1-Year), for LTEA (CAT-12) ECP-B-2Y EssentialCare+ B (2-Year), for LTEA (CAT-12) ECP-B-4Y EssentialCare+ B (4-Year), for LTEA (CAT-12) ECP-D-1Y EssentialCare+ D (1-Year), for 5G ECP-D-2Y EssentialCare+ D (2-Year), for 5G ECP-D-4Y EssentialCare+ D (4-Year), for 5G -
MAX Adapter (LTE)
- MAX Adapter
- 2x LTE Antennas (ACW-813)
- USB-C Female to USB-A Male Adapter
- USB-C Power Cable
MAX Adapter (5G)
- MAX Adapter 5G
- 4x LTE/5G LTE Antennas (ACW-235)
- USB-C Female to USB-A Male Adapter
- USB-C Power Cable
